Training Courses offered

Logical offers a Wide Range of Certified Instructor-led Training Courses in SOLIDWORKS 2021 & SOLIDWORKS Simulation 2021 from the Introductory Level to Customized Training and Mentoring Services. Our Engineers are Certified SolidWorks Professionals (CSWPs), which requires a greater amount of training and expertise than what is required to become a Certified Instructor for the SolidWorks Corporation.

We offer both classroom and on-site training on several standard SolidWorks courses. We can also customize the courses to our customers’ specific needs. Our onsite training classes run per regular schedules.

Courses Offered:

  • Basic Engineering Drawing
  • Basics 2D Drafting
  • SolidWorks Basics & the User Interface
  • Introduction to sketching
  • Basic part Modeling
  • Modeling a Casting or Forging
  • Patterning
  • Revolved Features
  • Shelling & Ribs
  • Editing repairs
  • Design changes
  • Configurations of Parts
  • Design tables & Equations
  • Using Drawings
  • Bottom-Up Assembly Modeling
  • Using Assemblies
  • File Management
  • Project

Course Duration:

30 Working Days

Courses Offered:

    • Fundamentals of Routing
    • Piping Routes
    • Piping Fittings
    • Tubing Routes
    • Piping and Tubing Changes
    • Creating Routing components
    • Using P&ID Files
    • Piping Skids
    • Using SOLIDWORKS Content

Course Duration:

05 Working Days

Courses Offered:

  • SolidWorks Drawings
  • Advanced Part Modeling
  • Advanced Assembly Modeling
  • Advanced Surface Modelling
  • Mold Design Using Solidworks
  • Sheet Metal
  • Weldments
  • SolidWorks Routing (Electrical)
  • Solidworks Routing (Piping & Tubing)
  • Photorealistic Rendering Using SolidWorks and PhotoView 360
  • SolidWorks Productivity Tools
  • Project

Course Duration:

30 Working Days

Solidworks Simulation/ Simulation Professional

This course is designed to make Solidworks users productive more quickly with the Solidworks Simulation Bundle. This course will provide an overview on the basics of Finite Element Analysis (FEA), covering the entire analysis process from meshing to evaluation of results for parts and assemblies, heat transfer analysis, frequency analysis, stability analysis based on the linear buckling concepts. The class discusses linear stress analysis, gap/contact analysis, and best practices.

Pre-Requisites: Knowledge of Solidworks and basic mechanical engineering concepts is recommended.

Who should attend: All Solidworks Simulation users wishing to create better designs in Solidworks by performing analysis and evaluating the behavior of their parts and assemblies under actual service conditions.

Course Duration: – 4 days
Time: 10:00 am to 5:00 pm.

Topics Covered in this course

  • Introduction to FEA
  • The Analysis Process
  • Mesh Controls, Stress Concentrations, and Boundary Conditions
  • Assembly Analysis with Contacts
  • Symmetry, Axi-symmetry, and cyclic symmetry
  • Assembly Analysis with Connectors
  • Compatible/Incompatible Meshes
  • Assembly Analysis Mesh Refinement
  • Analysis of Thin Components
  • Mixed Meshing Shells & Solids
  • Mixed Meshing Solids, Beams & Shells
  • Thermal Stress Analysis
  • Adaptive Meshing
  • Large Displacement Analysis
  • Frequency Analysis of Parts and Assemblies
  • Buckling Analysis
  • Thermal Analysis
  • Drop Test Analysis
  • Optimization Analysis

SOLIDWORKS Motion

Designed for users who would like to become productive quickly in using SOLIDWORKS Motion. This – day course will teach you how to use the SOLIDWORKS Motion simulation package to study the kinematics and dynamic behavior of your SOLIDWORKS assembly models.

Pre-requisites: Knowledge of SOLIDWORKS and basic mechanical engineering concepts is recommended.

Who should attend: This course has been designed for new SOLIDWORKS Motion users who would like to learn to perform motion analysis on their designs. The course provides an in-depth session on the basics of building, simulating and refining a mechanical design system.

Course Duration: – 2 days

Time: 10:00 am to 5:00 pm.

Topics Covered in this course

Basics

  • Introduction to Motion Simulation
  • Action/Reaction forces and moments
  • Introduction to Contacts, Springs, and Dampers
  • Building models for kinematic analysis
  • Create displacement, velocity, acceleration and force graphs
  • Contact and Friction
  • Motor Input and Force Input Types
  • Impact forces
  • Functional Expressions
  • Typical Redundant Mechanisms
  • Flexible connectors ‐ Bushings
  • 3D Contact to simulate realistic interaction between parts

Advanced Topics

  • Export of results to SolidWorks Simulation (stress analysis)
  • Event-Based Motion Simulation

SOLIDWORKS Flow Simulation

Designed for users who would like to become productive faster, this introductory course offers hands-on training on the use of SOLIDWORKS Flow Simulation.

Prerequisites: Some experience using SOLIDWORKS.

Who should attend: The two-day training program provides an in-depth session on the basics of fluid flow analysis, in addition to covering meshing concerns, modeling concerns, analysis, post-processing, available options, and preferences.

Course Duration: – 2 days

Time: 10:00 am to 5:00 pm.

Topics Covered in this course

Basics

  • Introduction to Fluid Flow
  • Model Preparation
  • Internal Flow Analysis
  • External Flow Analysis
  • Steady State
  • Transient Analysis
  • Computational Mesh
  • EFD Zooming
  • FEA Load Transfer
  • Compressible and incompressible
  • Newtonian / non-Newtonian fluid
  • Fan Curves
  • Particle trajectories
  • Supersonic Flows
  • Cavitation
  • Relative humidity
  • Conjugate heat transfer

Advanced Topics

  • Manual mesh control
  • Manual convergence
  • Export of results to SOLIDWORKS Simulation modulus (stress analysis)

Courses Offered:

  • Basic Electrical Drawing ( A Review)
  • Basics 2D Drafting (An Overview)
  • Lesson 1: SolidWorks Basics & the User Interface
  • Lesson 2: Project Templates
  • Lesson 3: Drawing Types
  • Lesson 4: Symbols and components
  • Lesson 5: Manufacturer parts
  • Lesson 6: Wires and Equipotentials
  • Lesson 7: Cabling
  • Lesson 8: Symbol creation
  • Lesson 9: Macros
  • Lesson 10: Cross-referencing
  • Lesson 11: Managing origin
  • Lesson 12: Dynamic PLC
  • Lesson 13: Automated PLC
  • Lesson 14: Connectors
  • Lesson 15: 2D Cabinet Layouts
  • Lesson 16: Design Rule Checks
  • Lesson 17: Reports
  • Project

Course Duration:

10 Working Days

Courses Offered:

  • What is Solidworks Electrical 2D
  • Basic Engineering Drawing ( A Review)
  • SOLIDWORKS Essentials

  • Lesson 1: SOLIDWORKS Basics & the User Interface
  • Lesson 2: Introduction to sketching
  • Lesson 3: Basic part Modeling
  • Lesson 4: Symmetry and Draft
  • Lesson 5: Patterning
  • Lesson 6: Revolved Features
  • Lesson 7: Shelling & Ribs
  • Lesson 8: Editing repairs
  • Lesson 9: Design changes
  • Lesson 10: Configurations
  • Lesson 11: Using Drawings
  • Lesson 12: Bottom-Up Assembly Modeling
  • Lesson 13: Using Assemblies
  • Lesson 14: File Management
  • SOLIDWORKS Electrical 3D

  • Lesson 1: Assembly Creation
  • Lesson 2: Cabinets, Ducts, Rails
  • Lesson 3: Component Intelligence
  • Lesson 4: Components
  • Lesson 5: Route Wires
  • Lesson 6: Route Cables
  • Lesson 7: 3D Error Analysis
  • Lesson 8: Line Diagram Harness
  • Lesson 9: Printed Circuit Boards
  • Lesson 10: Library and Classification management
  • Lesson 11: Import DXF DWG Files
  • Lesson 12: Import Manufacturer parts
  • Lesson 13: ERP Database Connection
  • Lesson 14: Importing and Exporting data from MS Excel
  • Lesson 15: Report Creation
  • Project

Course Duration:

24 Working Days

Courses Offered:

    • Fundamentals of Electrical Routing
    • Basic Electrical Routing
    • Routing with Clips
    • Electrical Routing Components
    • Standard Cables
    • Electrical Data Import
    • Electrical Drawing
    • Electrical Ribbon Cables
    • Electrical Conduits

Course Duration:

05 Working Days

  • Advance Diploma in CAD
  • Advance Diploma in CAD/CAE
  • Advance Diploma in CAD/CAM/CAE
